مشخصات محصول
رله همه منظوره مدل RH1B-UL
مشخصات فنی
مشخصات فنی
ویژگی مشخصات
برند Brand
ایدک IDEC
کشور سازنده Country of origin
ژاپن Japan
جنس کنتاکت Contact Material
Silver Cadmium Oxide
مقاومت کنتاکت Contact Resistance
50mΩ maximum
حداقل جریان مورد نیاز Minimum Applicable Load
24V DC/30mA, 5V DC/100mA
Operating Time
20ms Maximum
Release Time
20ms Maximum
Maximum Continuous Applied Voltge (AC/DC) at 20°C
110%Of the rated voltage
Minimum Operating Voltage (AC/DC) at 20°C
80%Of the rated voltage
Drop out Voltage (AC)
30%Or more of the rated voltage
Drop out Voltage (DC)
10%Or more of the rated voltage
Power Consumption
DC:0.9W, AC:1.4VA(50Hz), 1.2VA(60Hz)
مقاومت عایقی Insulation Resistance
100MΩ minimum
Dielectric Strength
Between live and dead parts: 2,000V AC, 1 minute/Between contact circuit and operating coil: 2,000V AC, 1minute/Between contact circuit : 2,000V AC, 1minute/Between contact of the same pole: 1,000V AC, 1minute
Frequency Response
1800Operation/hour
Temperature Rise
Coil: 85°C Maximum, Contact: 65°C Maximum
Life Expectancy
Electrical: over 500,000 operations at 120V AC, 10A/Mechanical: 50,000,000 Operations
دمای عملکرد ( Operating Temperature(°C
30/70-
Contact Configuration
SPDT
Indicator Light
دارد
Coil Voltage
AC110~120V
